ZP Control AdPro
ZP Control AdPro
Product number:
20293
ZP Control AdPro
Product number:
20293
Model:
- Precisely adjustable start pressure: 1.5 - 3.5 bar
- Integrated dry-run protection
- Protection against pressure surges
- Equipped with the ART system (Automatic Reset Test): In case of dry running, the system stops automatically and restarts periodically and automatically Protection class IP 65
Applications:
- The Ad Pro is a compact device for the automatic control and protection of electric pumps. It combines a pressure switch, float switch, and check valve
| Frequency: | 50/60 |
|---|---|
| Packing (WxHxL): | 160 x 230 x 160 |
| Voltage [V]: | 230 |
| C [µF]: | 10, 60 |
