Vectis 400
Vectis 400
Product number:
21664
Vectis 400
Product number:
21664
- Submersible waste water pump made of plastic
- Max. flow rate: 7,0 m³/h
- Max. head: 7,5 m
- Input power P1: 400 W
- Output power P2: 300 W
- Solids handling: 10 mm
- Pressure outlet: 1 1/4" external thread
Model
- submersible waste water pump, made of corrosion- and shock-resistant polypropylene and high-grade stainless steel
- motor winding with thermal winding protection
- triple sealing by shaft sealing rings
- integrated vent screw
- horizontal pressure outlet 1 ¼” MPT
- automatic mode due lever float switch
- flat suction function due removable suction strainer
- max. media temperature: 35°C
- protection grade IP 68 – fully submersible
Application
- pumping of clear water and waste water from pits, drainage manholes, cellars etc.
- portable pump for emergency drainage
- drainage of domestic waste water without faeces from showers, washing machines, washbasins etc.
Scope of delivery
- pump with 10 m power cable and plug
- 90° hose connecting bend
- locking device for continuous operation
- non return valve
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Head up to [m]: | 7.0 |
| Installation location: | outside buildings, portable, pump sump |
| Max. flow rate [m³/h]: | 7.5, 8 |
| Max. temperature [°C]: | 35 |
| Nominal current [A]: | 1.4 |
| Packing (WxHxL): | 260 x 290 x 240 |
| Power P2 [W]: | 200 |
| Pumped medium: | clear water, rainwater, waste water |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230, 400 |
| C [µF]: | 10 |
