Solida 290 / 390 / 490 - vortex impeller
Solida 290 / 390 / 490 - vortex impeller
Product number:
19047
Solida 290 / 390 / 490 - vortex impeller
Product number:
19047
- Grey water submersible pump made of stainless steel and cast iron
- Max. flow rate: 39,0 m³/h
- Max. head: 11,0 m
- Input power P1: 1.450 W
- Output power P2: 1.100 W
- Pressure outlet: 2"
Model
- submersible motor pump with recessed impeller
- float switch for automatic operation and dry-running protection
- double end face mechanical seal in oil chamber
- immersion depth 20 m
Application
- drainage
- agriculture
- suited for contaminated water with particulates
- maximum grain size 50 mm
Scope of delivery
- including cable H 07 RN-F, 10 m long and plug (230 V only)
| Application: | Disposal |
|---|---|
| Frequency: | 50 |
| Head up to [m]: | 11.0 |
| Installation location: | outside buildings, portable, pump sump |
| Max. flow rate [m³/h]: | 39.0 |
| Max. temperature [°C]: | 45 |
| Nominal current [A]: | 2.7 |
| Power P2 [W]: | 1.100 |
| Pumped medium: | clear water, rainwater, waste water |
| Solids handling [mm]: | 50 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 400 |
