S-SWH 100
S-SWH 100
Product number:
11466
S-SWH 100
Product number:
11466
- Waste water lifting unit for conveying slightly acidic condensate, aggressive or saline media (max. 15% salt content).
- Max. flow rate: 8,0 m³/h
- Max. head: 6,0 m
- Input power P1: 300 W
- Output power P2: 130 W
- Solids handling: 10 mm
- Pressure outlet: 1 1/4" IT
Model
- for use behind water softening systems and for calorific value condensate
- high-quality, silicon carbide mechanical seal, stainless steel motor housing (1.4404), stainless steel motor shaft
- additional connection of shower, washbasin and washing machine possible
- integrated audible alarm
- pump fixed on lid -> easy cleaning and maintenance
- potential-free alarm transmission
- 20 litres container volume
- pressure outlet 1 ¼“ FPT with integrated non-return valve
Application
- drainage of slightly acidic condensate, aggressive or salty media (max. 15% salt content)
- lifting of domestic faecal-free waste water (operation temperature 40°C / short-term up to 90°C)
Scope of delivery
- pre-assembled ready for connection with 1,5 m power cable and plug
| Application: | Disposal |
|---|---|
| Features: | Reedkontakt |
| Frequency: | 50 |
| Head up to [m]: | 8.0 |
| Installation location: | inside buildings |
| Max. temperature [°C]: | 40 (kurzzeitig 90) |
| Nominal current [A]: | 1.3 |
| Packing (WxHxL): | 245 x 400 x 405 |
| Power P1 [W]: | 300 |
| Power P2 [W]: | 130 |
| Pumped medium: | condensate, waste water |
| Solids handling [mm]: | 5 |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 10 |
