Microboy Pro

Product number: 18190

Product number: 18190

Type

Request an offer

Model

reduced noise during cutting
adjustable cutting gap for permanently optimal cutting results
optimized cutting system made of corrosion-resistant special steel 1.4112 with special hardness, wear resistance and cutting performance
terpolymer container for direct connection to EURO-Toilets with minimum inlet height
4 additional lateral inlets DN 40 for connection of washbasin, shower or bidet
container ventilation via active carbon filter
robust, dry installed vortex pump with stainless steel cutting system
alarm signal in case of fault
emergency discharge possible via motor shaft with slot
pressure outlet 1 ¼“ IG with integrated non-return valve, optionally left or right
operation temperature max. 40°C
protection grade IP 54 - protected against splashing water

Application

cuts wipes and female hygiene products
particularly suitable for publicly accessible sanitary facilities
single-toilet lifting unit for restricted domestic use according to EN 1825-3 below the backflow level e.g. in cellars or for the refurbishment of old buildings

Scope of delivery

pre-assembled ready for connection with 1,5 m power cable and plug audible alarm included

Data sheet

Application:	Disposal
Features:	mit pneumatischer Pumpensteuerung für Einzelpumpen
Frequency:	50
Head up to [m]:	11.8
Installation location:	inside buildings
Max. flow rate [m³/h]:	7.5
Max. temperature [°C]:	40 (kurzzeitig 90)
Nominal current [A]:	2.5
Packing (WxHxL):	300 x 300 x 490
Power P1 [W]:	600
Power P2 [W]:	350
Pumped medium:	sewage containing faeces, waste water
Speed [U/min]:	2800
Voltage [V]:	230
C [µF]:	10
