Flood emergency kit E-ZW
Flood emergency kit E-ZW
Product number:
16916
Flood emergency kit E-ZW
Product number:
16916
- Pump combination for all-purpose use with stainless steel submersible pump E-ZW 65 A
- Max. flow rate: 9,5 m³/h
- Max. head: 14,0 m
- Input power P1: 850 W
- Output power P2: 430 W
- Solids handling: 10 mm
- Pressure outlet: Storz coupling type C
Model
- submersible waste water pump made of stainless steel
- motor winding with thermal winding protection
- mechanical seal and additional shaft seal
- pump housing, motor housing, shaft and suction strainer are made of stainless steel, impeller made of polyamide
- jacket cooled mono-phase motor
- float switch for level control
- protection grade IP 68 – fully submersible
Application
- portable box for emergency drainage
- pumping of (invasive) ground water and high water
- pump can be easily removed and used outside the box
Scope of delivery
- stainless steel pump E-ZW 65 A with integrated non-return valve, float switch with float hinge and mounting bracket to fix the pump in the box, 10 m power cable and Storz coupling C
- 15 m hose with Storz coupling C with polyethylene kink protection
- protective box with 8 x 8 mm holes
| Application: | Disposal |
|---|---|
| Features: | mit Schwimmerschalter |
| Frequency: | 50 |
| Head up to [m]: | 14.0 |
| Installation location: | inside buildings, outside buildings, portable, pump sump |
| Max. flow rate [m³/h]: | 8 |
| Max. temperature [°C]: | 40 (kurzzeitig 90) |
| Nominal current [A]: | 3.7, 9.5 |
| Packing (WxHxL): | 400 x 300 x 600 |
| Power P1 [W]: | 850 |
| Power P2 [W]: | 430 |
| Pumped medium: | clear water, rainwater, waste water |
| Speed [U/min]: | 2800 |
| Voltage [V]: | 230 |
| C [µF]: | 10 |
