Domestic water systems CPS with Kit 05
Domestic water systems CPS with Kit 05
Product number:
18742
Domestic water systems CPS with Kit 05
Product number:
18742
- Self-priming, multi-stage centrifugal pump with automatic switch Kit 05 Optimatic
- Max. flow rate: 4,0 m³/h
- Max. head: 40,0 m
- Input power P1: 900 W
- Output power P2: 700 W
- Pressure outlet: 1" external thread (Kit 05 Optimatic)
Model
- self-priming, maintenance-free, multi-stage, horizontal centrifugal pump
- Kit 05 Optimatic: Suction socket 1", pressure socket 1"
- Kit 05 Optimatic: When one of the consumers gets opened, the pump automatically switches on. When all the consumers are closed, the pump is automatically switched off. Additional dry-run protection and auto-reset-function
- suction and discharge case made of alpha brass
- guide wheels made of special Noryl®
- O-rings made of NBR
- Case, Kit-05 PRO, PPO recyclable
Application
- complete water supply package for: Rainwater utilization plants, irrigation, pressure boost, clear water without aggressive and abrasive matters
| Application: | Supply |
|---|---|
| Features: | with electronic pressure switch |
| Frequency: | 50 |
| Installation location: | inside buildings |
| Max. flow rate [m³/h]: | 4.0, 40.0 |
| Max. temperature [°C]: | 40 |
| Packing (WxHxL): | 470 x 250 x 450 |
| Power P1 [W]: | 900 |
| Pumped medium: | clear water, rainwater |
| Speed [U/min]: | 2850 |
| Voltage [V]: | 230 |
| C [µF]: | 16 |
