CPS 25-4 B 400V
CPS 25-4 B 400V
Product number:
18602
CPS 25-4 B 400V
Product number:
18602
- Self-priming, horizontal, multistage centrifugal pump with stainless steel impellers
- Max. flow rate: 8,7 m³/h
- Max. head: 50,0 m
- Input power P1: 1.650 W
- Output power P2: 1.300 W
- Pressure outlet: 1" Internal thread
Model
- Self-priming, maintenance-free, multi-stage, horizontal centrifugal pump
- High efficiency Suction and pressure ports, internal thread (1" - 1¼")
- CPS SM with on/off switch
- CPS GG/SM: Suction and pressure housing made of gray cast iron
- CPS B: Suction and pressure housing made of dezincification-resistant α-brass Impellers made of glass-fiber-reinforced Noryl®
Applications
- Household water supply
- Rainwater harvesting
- Pressure boosting
- Irrigation for clear water without aggressive and abrasive components
Scope of delivery
- Pre-wired, incl. 1.5 meters of power cable H07 RNF with plug
Application: | Supply |
---|---|
Frequency: | 50 |
Head up to [m]: | 50.0 |
Installation location: | inside buildings |
Max. flow rate [m³/h]: | 8.7 |
Max. temperature [°C]: | 40 |
Nominal current [A]: | 5.1/2.9 |
Packing (WxHxL): | 220 x 250 x 450 |
Power P1 [W]: | 1650 |
Pumped medium: | clear water, rainwater |
Speed [U/min]: | 2850 |
Voltage [V]: | 3~230/3~400 |
